產品詳情
| 序號 | 機組功率號 | 機組結構形式 | 機組型號 | kVA | kWe | 濰柴牌發動機型號 | 敞開式 | ||||||||
| MODEL | ESP | PRP | ESP | PRP | 型號 | 額定負載燃油耗 (L/h) | 缸數 |
缸徑 × 沖程 (mm) | 長L (mm) | 寬W (mm) | 高H (mm) | 凈重 (kg) | |||
| 1 | 1C1400_4GN | B、C | WPG1925*73 | 1925 | 1750 | 1540 | 1400 | 16M33D1680E310 | 364.7 | 16 | 150×185 | 5800 | 2300 | 2900 | 12400 |
| 2 | 1C1400_4GN | B | WPG1875*73 | 1875 | / | 1500 | / | 16M33D1680E310 | 394 | 16 | 150×185 | 5800 | 2300 | 2900 | 12500 |
| 3 | 1C1500_4GN | B、C | WPG2062*73 | 2062 | 1875 | 1650 | 1500 | 16M33D1800E310 | 394 | 16 | 150×185 | 5800 | 2300 | 2900 | 12500 |
| 4 | 1C1600_4GN | B | WPG2250*73 | 2250 | 2000 | 1800 | 1600 | 16M33D1980E310 | 415 | 16 | 150×185 | 5800 | 2300 | 2900 | 12900 |
| 5 | 1C1800_4GN | B、C | WPG2500*73 | 2500 | 2250 | 2000 | 1800 | 20M33D2210E310 | 460 | 20 | 150×185 | 6500 | 2620 | 2960 | 16400 |
| 6 | 1C1800_4GN | B、C | WPG2500*73 | 2500 | 2250 | 2000 | 1800 | 12M55D2210E310 | 455 | 12 | 180×215 | 6660 | 2680 | 2960 | 20000 |
| 7 | 1C2000_4GN | B、C | WPG2750*73 | 2750 | 2500 | 2200 | 2000 | 12M55D2450E310 | 505 | 12 | 180×215 | 6760 | 2680 | 2960 | 20700 |
| 8 | 1C2200_4GN | B、C | WPG3025*73 | 3025 | 2750 | 2420 | 2200 | 12M55D2700E310 | 535 | 12 | 180×215 | 6760 | 2680 | 2960 | 21300 |
| 9 | 1C2400_4GN | B、C | WPG3300*73 | 3300 | 3000 | 2640 | 2400 | 16M55D2900E310 | 590 | 16 | 180×215 | 7100 | 3000 | 3580 | 24400 |
| 10 | 1C2600_4GN | B、C | WPG3575*73 | 3575 | 3250 | 2860 | 2600 | 16M55D3300E310 | 640 | 16 | 180×215 | 7100 | 3000 | 3580 | 24500 |
| 11 | 1C3000_4GN | B、C | WPG4125*73 | 4125 | 3750 | 3300 | 3000 | 16M55D3600E310 | 760 | 16 | 180×215 | 7280 | 3000 | 3760 | 25200 |
